FLEX FORK (G1)

Product number
impact_130m_fc1-500-75ds_g1flex
This tool makes it possible to adapt the width to different box dimensions.The tool is made up of two fork arms (two horizontal and parallel fork arms) mounted in a frame, making it easy to adjust their width. The lifter is designed for boxes with that are 210–589 mm wide with longitudinal grooves or a collar (rim).

Specification

Tool type Tool type:
Fork
Lifting capacity Lifting capacity:
100.00 kg
Lifts per charge Lifts per charge:
80
Lifting height Lifting height:
1,631.00 mm
Total width Total width:
782.00 mm
Total height Total height:
1,924.00 mm
Total length Total length:
924.00 mm
Customize FLEX FORK (G1)
1 x IMPACT 130M;
1 x FC1-500-75ds;
1 x Flex fork;

* Required Fields

Your Customization
Convey the box to its destination and put it down by lowering the fork (by pressing a button).
FLEX FORK (G1)

In stock

Summary

    Details

    The tool only work for boxes with longitudinal grooves or a collar (rim).
    If you frequently need to reset the fork width to fit differently sized boxes, we recommend using fixed-width forks which can be quickly interchanged with our Quick Change bracket.
